Horizontal Bend 12x17mm LED Neon Flex Cool White 6K or Warm White 3K

10M Kit Inc. Driver

The NEONTOP1217/10MKIT-CW is a professional-grade Cool or Warm White LED Neon Flex system, specifically designed for crisp, modern architectural accents and high-visibility signage. This Horizontal Bend profile is engineered to curve side-to-side, allowing it to follow the natural lines of walls, counters, and curved building features with ease.

Constructed from premium molded silicone, this neon flex provides a completely uniform, dot-free linear light in a sharp 6000K Cool White or 3000K Warm White. It is built to endure the elements, making it suitable for both high-end interior joinery and exterior architectural definition. This 10-metre kit is optimized for dual-end powering to ensure 100% brightness and zero voltage drop across the entire run.

Key Features

✅ Horizontal Bend Technology: Designed to bend horizontally relative to the light output—ideal for wrapping around curved surfaces.
✅ Superior Light Quality: Features a high CRI of >90 for accurate color representation and a professional finish.
✅ Fully Diffused: Advanced silicone construction ensures a smooth, neon-style glow with no visible hotspots or shadowing.
✅ Full Working System: Comprehensive kit includes 10m Neon Flex, an On/Off Power Supply, and mounting clips.
✅ Weatherproof & Impact Resistant: IP67 rated against water ingress and IK08 rated for protection against physical impact.
✅ Precision Cutting: Short 50mm cut points allow for a precise fit in bespoke installations.

Technical Specifications

☑️ Dimensions: 12mm x 17mm x 10,000mm
☑️ Voltage: 24VDC
☑️ Power Consumption: 10.6 Watts per metre
☑️ Colour Temperature: 6000K (Cool White) / Warm White (3000K)
☑️ Luminous Flux: 460 Lumens per metre
☑️ Minimum Bend Radius: 60mm
☑️ CRI: >90 CRI
☑️ Cutting Points: Every 50mm
☑️ IP/IK Rating: IP67 / IK08
☑️ Warranty: 3 Years
☑️ Certifications: CE, RoHs, UL, and REACH

Dimming & Smart Home Compatibility

The included driver is a standard On/Off unit. However, the Neon Flex itself is fully compatible with professional control protocols when integrated with a dimmable driver or controller:

✅ Protocols: Triac, DMX, Dali, 0-10V, and PWM.
✅ Smart Systems: RTI, Lutron, Loxone, Rako, Control 4, Lightwave, Wiz, Casambi, and Crestron.

Included in the Kit

☑️ 10 Metre Horizontal Bend Cool White Neon Flex
☑️ 24V On/Off Power Supply Driver
☑️ Pack of 4 Mounting Clips (Additional clips available on request)

CALL FOR PROJECT DISCOUNTS: We offer volume pricing and FREE expert design advice for large installations. If you require specialized mounting channels, made-to-order lengths, or dimming assistance, please call our technical team on 0161 737 7333 or email us to discuss your project.
