Description
ELED-20-V Series
0-10V/1-10V Dimmable Ecopac Constant Voltage LED Drivers 20W
Features
- 0-10V/ Potentiometer/10V PWM dimmable
- Constant voltage design
- Universal AC input/ Full range
- Fully isolated plastic case with terminals IP20
- Protections: Short circuit/ Overload/ Over voltage/ Over temp.
- Built-in PFC function (PFC>0.98)
- Cooling by free air convection
- Over 83% efficiency
- Suitable for LED lighting and moving sign applications
- Compliance to worldwide safety regulations for lighting
Options
- ELED-20-12V
- ELED-20-24V
A compact driver for 0-10V, controllable dimming. Connected in-line before the first light fitting, this driver enables full dimming of the LED product required. With this LED driver your controllable loads such as LED down lights and general LED dimmable lighting. Controlled from any 0~10v device, for example we recommend RAKO infrastructure because we have tested there systems and these items work and dim perfectly together.
