Description
Rako RMT-1200 Wireless 1200W Trailing-Edge Dimmer
The RMT-1200 provides a high-capacity wireless trailing-edge dimming solution, specifically engineered for large-scale Mains LED loads and electronic low-voltage transformers. Designed to handle significant power requirements up to 1200W, this robust module integrates seamlessly into any Rako wireless ecosystem to provide sophisticated control for expansive residential or commercial circuits.
We engineered the RMT-1200 for maximum reliability in modern digital lighting environments, featuring integrated short-circuit protection and thermal shutdown. You can control the module from the full range of Rako transmitters, including RCM, RNC, and the elegant EOS/MOD keypads. With non-volatile memory for 16 custom scenes and fully adjustable dimming profiles, it delivers professional-grade management for high-wattage LED installations.
Key Features
- ✅ High-Capacity LED Dimming: Specifically optimized for heavy LED loads, managing up to 600W of Mains LED lighting.
- ✅ Advanced Protection: Features built-in short-circuit protection and thermal shutdown to safeguard your infrastructure.
- ✅ Precision Control: Fully programmable via Rasoft software to customize fade rates and dimming curves for flicker-free performance.
- ✅ Versatile Ecosystem: Communicates with all Rako wireless keypads, handheld remotes, and Bridge/HUB units.
- ✅ System Feedback: Includes an LED diagnostic light for instant status updates and easier commissioning.
- ✅ Local Override: Equipped with a manual test and programming button for immediate local operation.
Technical Specifications
| Specification | Details |
|---|---|
| Max Load (Mains LED) | 600W |
| Max Load (Electronic Transformer) | 1080W |
| Load Range | Minimum 1W |
| Input Supply | 230V AC 50Hz |
| Dimensions | 190mm x 105mm x 66mm |
| Communication | Rakom RF (433.9MHz) |
Installation & Safety Note
⚠️ Load Compatibility: The RMT-1200 uses trailing-edge dimming technology. While perfect for LEDs and electronic transformers, it is not suitable for inductive loads such as wire-wound (magnetic) transformers. For inductive or leading-edge only loads, please refer to the RML-1200.
Professional Support
We specialize in high-capacity Rako wireless infrastructure and modern LED dimming topography. If you need technical assistance calculating your total LED circuit load, advice on mounting requirements for the RMT-1200, or a FREE full lighting design, please call our specialist team on 0161 737 7333 or send us an email. Our team will help you achieve a robust and perfectly controlled lighting installation.
