Description

SCP CAT6 HDBaseT Certified Cable – 23AWG U/UTP DCA Rated, 305m (Violet, Blue, Green, Red)

The SCP HNC CAT6 cable is an HDBaseT™ certified Category 6 solution engineered to deliver superior performance for professional HDBaseT devices and high-speed networking applications.

Manufactured by Structured Cable Products (SCP), a global leader in low-voltage cable solutions for residential and commercial custom installation, Pro A/V, security, satellite, and Data/Telecom markets, this cable is designed to outperform standard CAT6 cables in demanding environments.

Optimised with four balanced twisted pairs and a centre spline on 23AWG insulated solid bare copper conductors, the HNC CAT6 enhances signal integrity and ensures stable electrical performance. The round, flexible PVC jacket allows easy pulling and stripping, making it installer-friendly and efficient on-site.

Each pull box includes a certified test report and is recognised as an industry-best pull box design. This cable is also recommended by WyreStorm for professional AV installations.

Designed with a round, flexible profile, the LSZH jacket allows easy pulling and stripping for professional installers.

Smart Control Recommendation

Fully compatible with HDBaseT systems, structured cabling infrastructure, and commercial or residential AV installations requiring stable, high-performance signal transmission.

Customisation & Build Options

• Conductor: 23AWG Solid Bare Copper

• Configuration: 4 Balanced Twisted Pairs

• Separator: Centre Spline

• Cable Type: U/UTP

• Jacket: PVC

• Fire Rating: DCA (Indoor Rated)

• Length: 305m

• Colours Available: Blue | Green | Red

Key Features

✅ HDBaseT™ Certified CAT6 performance
✅ 23AWG solid bare copper conductors
✅ 4 balanced twisted pairs with centre spline
✅ DCA rated for indoor installations
✅ Improved signal integrity
✅ Stable electrical performance
✅ Certified test report included in each box
✅ Industry-best pull box design
✅ Recommended by WyreStorm®
✅ Flexible round cable for easy installation

Technical Specifications

☑️ Cable Type: CAT6 U/UTP
☑️ Conductor Size: 23AWG
☑️ Conductor Material: Solid Bare Copper
☑️ Pairs: 4 Balanced Twisted Pairs
☑️ Separator: Centre Spline
☑️ Jacket: PVC
☑️ Fire Rating: DCA
☑️ Length: 305m
☑️ Colours: Blue, Green, Red
☑️ Standards: TIA/EIA 568-C.2 Category 6, ISO/IEC 11801 Ed2 Class E, EN 50173-1:2011

Control System Compatibility

☑️ HDBaseT AV Distribution
☑️ Structured Cabling Networks
☑️ Commercial Networking Infrastructure
☑️ Residential Custom Installation
☑️ Pro A/V Systems

Applications

🏢 Commercial office networking
🏠 Residential structured cabling
🎥 Professional AV & HDBaseT installations
📡 Data cabinets & telecom rooms
🏨 Hospitality & smart building infrastructure

Why Choose SCP HNC CAT6?

🚀 HDBaseT certified performance
🛡️ DCA indoor fire-rated compliance
🎛️ Optimised centre spline for improved signal integrity
📏 Solid copper conductors for reliable transmission
🔧 Installer-friendly flexible design
📦 Certified test report in every box

Additional Information

🌟 Suitable for high-speed data, voice, and HD AV transmission
🛠️ Designed for professional installers and integrators
🚚 Bulk supply available
