22W per Metre – 24V LED Ribbon Tape (Constant Current)
The PRO Series 22W Constant Current LED Ribbon Tape is a high-output professional lighting solution designed for demanding architectural, commercial and specialist feature lighting applications. Built using advanced Samsung 5630 LED chip technology, this ribbon delivers exceptional brightness, excellent efficiency and reliable long-run consistency — making it ideal for large-scale installations requiring powerful, uniform illumination.
Manufactured to any project length and costed per metre, this LED ribbon is engineered for premium performance. When installed with our aluminium heat-sink channel and FREE LED Surge Protection Module (SPM supplied on orders over £500), the PRO Series qualifies for a full 5-year warranty.
Integrated thermal protection is available upon request and automatically reduces output when overheating is detected, ensuring longevity and safeguarding the LED system.
Call for project quotations & trade discounts
Key Features
- ✅ High-power LED ribbon — 22W per metre
- ✅ Samsung 5630 LEDs — 128 LEDs per metre
- ✅ Exceptional light output — 2900 lm per metre
- ✅ Constant current regulation for long-run stability
- ✅ Optional thermal safety protection
- ✅ Custom lengths available for all project types
- ✅ 5-year warranty with heat-sink + Surge Protection Module
Technical Specifications
-
- ☑️ Power Consumption: 22 W per metre
- ☑️ Supply Voltage: 24 V DC (constant voltage)
- ☑️ LED Technology: Constant Current Regulation
- ☑️ Lumen Output: 2900 lm per metre
- ☑️ Beam Angle: 120°
- ☑️ LED Chip Type: Samsung 5630 / 128 LEDs per metre
- ☑️ Cutting Points: Every 8 LEDs
- ☑️ IP Rating Options: IP20 / IP67 / IP68
- ☑️ CRI: >80 Ra
- ☑️ CCT/Colour Options: 3000K / 4000K / 5500K / Red / Green / Blue
- ☑️ Dimensions: 1m × 12mm × 2mm (custom lengths available)
- ☑️ Lifetime: 30,000 hours (installation & environment dependent)
- ☑️ Control System Compatibility: Lutron, Rako, Mode, Crestron
- ☑️ Additional Control Support: 1–10 V, Triac, DALI, DMX512
Applications
- 🎨 High-output architectural lighting
- 🏛️ Museums, galleries & large exhibitions
- 🏡 Residential feature lighting & premium task areas
- 🛍️ Retail, hospitality & commercial illumination
- 🌌 Star ceilings & bespoke LED lighting designs
Why Choose the 22W Constant Current Ribbon?
- 🚀 Superior brightness at 2900 lm per metre
- 💡 Samsung 5630 LED chips for maximum efficiency
- 🛡️ Optional thermal protection extends long-term reliability
- 🎛️ Integrates seamlessly with premium lighting control systems
- 📏 Bespoke manufacturing for perfect installation length
- 🔌 FREE Surge Protection Module on eligible orders
- 📐 Full support from GHS design & engineering team
Additional Information
- 🌟 FREE design assistance for lighting control & BMS integration
- 🛠️ Custom star ceiling manufacturing available
- 🛡️ 5-year warranty when installed with heat-sink & SPM
- 🚚 FREE delivery on orders over £100
