GHSMIZ-SL LED Exterior GOBO Projector — Bespoke Made-to-Order Image & Logo Projection
The GHSMIZ-SL LED Exterior GOBO Projector is a high-performance, bespoke made-to-order projection luminaire engineered for crisp, high-brightness image and logo projection onto walls, buildings, and outdoor surfaces. Designed for demanding exterior applications, it delivers powerful optical performance combined with advanced control features and exceptional all-weather reliability.
Ideal for creative, architectural, and commercial installations, the GHSMIZ-SL is perfectly suited to branding, wayfinding, architectural highlights, and promotional projection where clarity, brightness, and durability are essential.
We offer a full bespoke projection service including GOBO design support and can meet any specification. Please call our technical department if you require assistance — we provide FREE project consultation and specification support. Call our design team on 0161 737 7333.
Call for project quotations & bespoke GOBO pricing
Key Features
- ✅ Bespoke made-to-order LED image and logo projection luminaire
- ✅ High-output OSRAM LED options for long-throw exterior projection
- ✅ Static or rotating GOBO with adjustable rotation speeds
- ✅ Automatic dusk-to-dawn light sensing operation
- ✅ Multiple beam angles for precise projection control
- ✅ IP67-rated for harsh outdoor environments
Technical Specifications
- ☑️ Light Source: High-quality OSRAM LED
- ☑️ Rated Power: 40W / 60W
- ☑️ Luminous Flux:
- 40W: 4000–5000 lm
- 60W: 6000–7000 lm
- ☑️ Colour Temperature: 8000K – 9000K
- ☑️ Colour Rendering Index (CRI): ≥85 Ra
- ☑️ LED Lifetime: ≥30,000 hours
- ☑️ Forward Voltage: 12–18V
- ☑️ Battery Capacity: 20,000 mAh
- ☑️ Charging Time: 6–8 hours
- ☑️ Working Time: 5–7 hours
- ☑️ Available Beam Angles: 0.2 (11°) / 0.33 (17°) / 0.5 (28°) / 0.65 (36°) / 1.0 (53°)
- ☑️ Image Optics: 4 × HD optical lenses
- ☑️ GOBO Size: 37 mm diameter
- ☑️ Function Mode: Static or rotating (4-speed adjustable)
- ☑️ Running Mode: Automatic light sensing (on at dusk, off after 5–7 hours)
- ☑️ Projection Distance:
- Dark environment: 1–15 m
- Bright environment: 1–10 m
- ☑️ Adjustable Bracket Angle: 0–180°
- ☑️ Installation: Bracket mounting / Hoop mounting
- ☑️ Operating Temperature: -40 °C to +60 °C
- ☑️ Protection Rating: IP67
- ☑️ Safety Protection: Over-voltage, over-current, leakage, moisture protection
- ☑️ Dimensions: 530 × 700 × 400 mm
- ☑️ Weight: 9.25 kg
Applications
- ✅ Architectural façade and landmark projection
- ✅ Corporate branding and logo projection
- ✅ Wayfinding and directional signage
- ✅ Retail, hospitality, and commercial environments
- ✅ Promotional and permanent exterior installations
Why Choose GHSMIZ-SL?
- ✅ Bespoke made-to-order solution tailored to your project
- ✅ High-lumen output for demanding exterior projection
- ✅ Integrated battery with automatic dusk-to-dawn operation
- ✅ Multiple beam angles for precise image sizing
- ✅ IP67 construction for extreme outdoor conditions
Additional Information
- ✅ Custom GOBO artwork and design service available
- ✅ Project-based pricing and trade discounts
- ✅ FREE technical consultation and specification support
- ✅ Supplied by specialist architectural projection lighting engineers
