Description
Mean Well LPV-100 LED Driver – 100W Constant Voltage Power Supply
Call for project quotations and trade discounts
The Mean Well LPV-100 Series is a high-power 100W constant voltage LED driver, fully sealed and rugged. It’s suited for signage, architectural lighting, and outdoor LED infrastructure requiring dependable constant-voltage feed.
Key Features:
- ☑️ Power Rating: 100W (typical) :contentReference[oaicite:20]{index=20}
- ☑️ Input Voltage: 90–264VAC universal range :contentReference[oaicite:21]{index=21}
- ☑️ Output Voltage Options: 5V / 12V / 15V / 24V / 36V / 48V DC :contentReference[oaicite:22]{index=22}
- ☑️ Protection Features: Short circuit, overload, over voltage
- ☑️ Surge Tolerance: 300 VAC input surge for 5 seconds (common to LPV family) :contentReference[oaicite:23]{index=23}
- ☑️ Enclosure / Isolation: Fully encapsulated, Class II plastic case, IP67
- ☑️ Cooling: Free-air convection
- ☑️ Burn-in & Reliability: 100% full-load burn-in test
- ☑️ Warranty: 2 years :contentReference[oaicite:24]{index=24}
Applications:
- ☑️ Large signage, display and billboard lighting
- ☑️ LED façade and architectural lighting
- ☑️ Outdoor and commercial installations requiring stable 12–48V supply
Available Models:
- LPV-100-5 – 5V DC output
- LPV-100-12 – 12V DC output
- LPV-100-15 – 15V DC output
- LPV-100-24 – 24V DC output
- LPV-100-36 – 36V DC output
- LPV-100-48 – 48V DC output
Why Choose the Mean Well LPV-100?
- ✅ High output capacity for demanding LED systems
- ✅ Multiple voltage options for diverse applications
- ✅ IP67 encapsulation protects in harsh environments
- ✅ Reliable performance with safety and regulation compliance
