Mean Well LPV-35 Series Non-dim Constant Voltage LED Drivers 35W

Mean Well LPV-35 LED Driver – 35W Constant Voltage Power Supply

Call for project quotations and trade discounts

The Mean Well LPV-35 Series offers a robust 35W constant voltage LED driver in a fully sealed IP67 package. With multiple DC output options and built-in protections, it’s ideal for signage, architectural and general lighting uses.

Key Features:

• ☑️ Power Rating: 35W (standard) :contentReference[oaicite:9]{index=9}
• ☑️ Input Voltage: 90–264VAC universal input :contentReference[oaicite:10]{index=10}
• ☑️ Output Voltage Options: 5V / 12V / 15V / 24V / 36V DC (typical) :contentReference[oaicite:11]{index=11}
• ☑️ Protective Features: Short circuit, overload, over voltage
• ☑️ Surge Withstand: 300 VAC input surge for 5 seconds (same spec family) :contentReference[oaicite:12]{index=12}
• ☑️ Enclosure / Isolation: Fully encapsulated, Class II plastic case, IP67
• ☑️ Cooling: Free-air convection
• ☑️ Burn-in & Reliability: 100% full-load burn-in test
• ☑️ Warranty: 2 years :contentReference[oaicite:13]{index=13}

Applications:

• ☑️ LED signage and channel letters
• ☑️ Strip lighting for retail and architectural accents
• ☑️ Outdoor feature lighting in protected installations

Available Models:

• LPV-35-5 – 5V DC output
• LPV-35-12 – 12V DC output
• LPV-35-15 – 15V DC output
• LPV-35-24 – 24V DC output
• LPV-35-36 – 36V DC output

Why Choose the Mean Well LPV-35?

• ✅ Wider range of voltage outputs for flexibility
• ✅ IP67 sealed design for harsh environments
• ✅ Built-in protections and surge handling
• ✅ Reliable Mean Well build and Ecopac stock availability :contentReference[oaicite:14]{index=14}

View manufacturer page on Mean Well website
