Description
DALI DIN rail SR-2303AC-4CH-DIN 4x400Watt Triac Phase Dimmer
Call for projects and trade discounts.
This DALI DIN rail mounted controller is designed in full compliance with the standard DALI protocol, ensuring seamless integration with modern lighting systems. The unit allows for flexible addressing, either through manual assignment displayed on its clear numeric digital screen or via automatic configuration by master controllers. Each address can operate synchronously, providing reliable communication across the network. With advanced logarithmic dimming technology, the controller delivers smooth and precise dimming performance from 0% to 100%, enabling comfortable and efficient lighting control. In addition, these decoders are fully compatible with leading systems such as Lutron, Rako, and Mode, making them a versatile solution for both residential and commercial lighting projects.
•In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2.
•Built-in DALI-2 interface, DALI DT6 device
•Match all DALI systems in the market
• Safe and reliable full isolation design
• DALI phase dimmer, trailing edge dimming
• Supports resistive loads and capacitive loads
• DALI signal input, DALI address can be set with buttons and displayed on the digital display
• DALI address quantity can be set as 1/2/3/4 to control 4 channels load simultaneously or separately
• 4 channels AC100-240V output
• To dim and switch single colour dimmable LED lamps, dimmable LED driver, traditional incandescent and halogen lights
• Din rail installation, easy and fast
• Waterproof grade: IP20
