SR-2001EA Sunricher 0-10Volt Decoder RGBW Constant Voltage
Call for project quotations and trade discounts
The SR-2001EA Sunricher 0-10Volt Decoder is a professional RGBW constant voltage controller for ultra-smooth dimming with zero flicker. Supporting 12–36VDC, this 4-channel output decoder is perfect for residential, commercial, and architectural LED projects.
Key Features:
- ✓ Voltage: 12 – 36VDC
- ✓ Channels: 1CH input / 4CH output
- ✓ Power: 8A – 12V@384W, 24V@768W, 36V@1152W
- ✓ Dimming: Smooth 0–10V dimming to 0.1% with no flicker or buzzing
- ✓ Control Methods: 1–10V potentiometer, push switch, or 1–10V analogue
- ✓ Output Type: PWM for precise RGBW control
Technical Specifications:
- Input Voltage: 12–36VDC
- Input Channels: 1CH 1–10V
- Output Channels: 4CH PWM
- Max Current: 8A total
- Power Output: 12V@384W, 24V@768W, 36V@1152W
Applications:
- RGBW LED lighting projects
- Architectural and commercial lighting systems
- Home and multi-room LED installations
Why Choose the SR-2001EA Sunricher Decoder?
- ✓ Ultra-smooth dimming down to 0.1% with no flicker
- ✓ Flexible 4-channel constant voltage output
- ✓ Compatible with multiple control methods
- ✓ Reliable, durable design for professional LED installations
- ✓ Ideal for precise RGBW colour control and effects
Please note: Ensure input voltage matches the 12–36VDC range for safe and optimal operation.
